4B FOG BRACKETS TYPE M

4B FOG BRACKETS TYPE M

Regular price$80.00
/
Shipping calculated at checkout.

  • Free worldwide shipping
  • In stock, ready to ship
  • Backordered, shipping soon
Introducing the Morimoto 4Banger Fog Lights: your ticket to superior visibility and style on the road. With SAE-compliant NCS and high-intensity HXB wide beam options, these fog lights redefine performance. Both the NCS & HXB offer exceptional brightness while adhering to street-legal standards, perfect for safety-conscious drivers. Meanwhile, the HXB boasts unrivaled power, making it the brightest SAE-compliant pod on the market for those who crave intensity. These fog lights are engineered for a seamless fit and easy installation, with no vehicle modifications required. Enjoy full adjustability to direct the beam precisely where you need it, and benefit from built-in cooling technology for extended lifespan. Whether you opt for the all-weather white output or the yellow-output version for adverse conditions, Morimoto 4Banger Fog Lights deliver unmatched performance and style, making them the ultimate choice for both on and off-road adventures. Upgrade your driving experience today!

FEATURES & BENEFITS

  • SAE Compliant: Street-legal fog lights, meeting SAE F regulations.
  • Intense Brightness: HXB Wide Beam sets an industry benchmark in brightness.
  • Easy Installation: Hassle-free bolt-on, plug-n-play design, no vehicle modifications.
  • Fully Adjustable: +/- 6 degrees vertical adjustability for precise beam placement.
  • All-Weather Performance: Choose white/yellow-output for optimal visibility in any weather.

WHAT’S INCLUDED

  • Fog Light Brackets: 2x (One Pair) BAF023 Brackets

  • LED Pods: 2x (One Pair) Morimoto 4Banger (Optional Color / Beam)

  • Hardware: Complete Pack (Stainless Steel)

  • Wiring: Plug N Play Connection Kit

WARRANTY INFORMATION

This Morimoto product includes a Lifetime limited warranty, serviced and supported by the Morimoto team in Atlanta, GA. This warranty does not cover modifications, alterations, or misuse. For additional information.

COMPATIBILITY

  • JEEP CHEROKEE: 2014-2017

  • JEEP GRAND CHEROKEE: 2011-2013

  • JEEP WRANGLER JK: 2007-2017

  • REPLACES MOPAR PART #: 5182026AA

COMPLIANCE

Wide beam photometrics are SAE F 20 compliant

TECHNICAL SPECIFICATIONS

  • Note: These specifications are per pod / each!

  • Intensity:

  • NCS Wide Yellow: 8,680 Cd (Post Warm-Up) (86.8lux @ 10m)

  • NCS Wide White: 14,400 Cd (Post Warm-Up) (144lux @ 10m)

  • HXB Wide White: 22,400 Cd (@20 Min / 21C Ambient) (224lux @ 10m)

  • Input Voltage: 9-18V DC

  • Power (stabilized): 15.6w (NCS) 42w (HXB)

  • Current: 1.5A (NCS) or 3.2A (HXB)

  • Peak Luminosity (lm)(Raw): 1,300lm (NCS), 3,000lm (HXB)

  • Dimensions: 82mm W, 67mm H, 60mm D

  • Color: 2400K (Yellow NCS), 2700K (Yellow HXB), 5600K (White NCS), or 5700K (White HXB))

  • Light Source: 3x Nichia NCSY131F, Nichia NCSW131F, or Osram HX Boost

  • Input: Proprietary Overmolded Deutsch DT 2-Pin

  • Material: Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum (Housing)
