4B FOG BRACKETS TYPE T2

4B FOG BRACKETS TYPE T2

Regular price$80.00
/
Tax included. Shipping calculated at checkout.

  • Free worldwide shipping
  • In stock, ready to ship
  • Backordered, shipping soon
Introducing the Morimoto 4Banger Fog Lights – your ultimate solution for superior visibility and style on the road! With our NCS Wide Beam and HXB Wide Beam models, you'll enjoy unparalleled brightness, compliant with SAE regulations for a safe and legal driving experience. Our easy setup and fully adjustable brackets ensure a hassle-free installation, while the air-cooled design guarantees top-notch performance without overheating. No matter the weather, our lights are ready to shine, with a white-output version for all-around visibility and a yellow-output option for adverse conditions. The HXB Wide Beam, featuring Osram HX Boost LEDs, offers an 80% brighter output than competitors, making it the brightest SAE-compliant fog light on the market. Meanwhile, the NCS Wide Beam stands out with its 14% greater brightness and 28% less power consumption compared to the closest competitor. Upgrade your vehicle with Morimoto 4Banger Fog Lights today and experience the perfect blend of power, control, and style on the road!

FEATURES & BENEFITS

  • Bright & Efficient: NCS Wide Beam for 14% more brightness, 28% less power.
  • Highest Brightness: HXB Wide Beam with Osram HX Boost LEDs, 80% brighter.
  • SAE-Compliant: Street-legal fog lights complying with SAE F regulations.
  • Easy Install: Plug-and-play, fully adjustable brackets for custom setup.
  • Cooling System: Integrated air-cooling for enhanced LED pod performance.

WHAT’S INCLUDED

  • Fog Light Brackets: 2x (One Pair) BAF019 Brackets

  • LED Pods: 2x (One Pair) Morimoto 4Banger (Optional Color / Beam)

  • Hardware: Complete Pack (Stainless Steel)

  • Wiring: Plug N Play Connection Kit

WARRANTY INFORMATION

This Morimoto product includes a Lifetime limited warranty, serviced and supported by the Morimoto team in Atlanta, GA. This warranty does not cover modifications, alterations, or misuse. For additional information.

COMPATIBILITY

  • TOYOTA SEQUOIA: 2008-2017

  • TOYOTA SOLARA: 2004-2006

  • TOYOTA TACOMA: 2005-2011

  • TOYOTA TUNDRA: 2007-2013

  • REPLACES TOYOTA PART #: 81210-AA030

COMPLIANCE

Wide beam photometrics are SAE F 20 compliant

TECHNICAL SPECIFICATIONS

  • Note: These specifications are per pod / each!

  • Intensity:

  • NCS Wide Yellow: 8,680 Cd (Post Warm-Up) (86.8lux @ 10m)

  • NCS Wide White: 14,400 Cd (Post Warm-Up) (144lux @ 10m)

  • HXB Wide White: 22,400 Cd (@20 Min / 21C Ambient) (224lux @ 10m)

  • Input Voltage: 9-18V DC

  • Power (stabilized): 15.6w (NCS) 42w (HXB)

  • Current: 1.5A (NCS) or 3.2A (HXB)

  • Peak Luminosity (lm)(Raw): 1,300lm (NCS), 3,000lm (HXB)

  • Dimensions: 82mm W, 67mm H, 60mm D

  • Color: 2400K (Yellow NCS), 2700K (Yellow HXB), 5600K (White NCS), or 5700K (White HXB))

  • Light Source: 3x Nichia NCSY131F, Nichia NCSW131F, or Osram HX Boost

  • Input: Proprietary Overmolded Deutsch DT 2-Pin

  • Material: Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum (Housing)
